Apogee Connect 8X8MP | modulkort 8x8 Analog I/O + 8x8 AES/Optical I/O + 8 mik pre

8×8 Analog I/O + 8×8 AES/Optical I/O + 8 Mic preamps 16 Channels of I/O simultaneously
Tillgänglighet: Loading...
Tillverkare: Apogee
Lagerstatus: Tillfälligt slut - skickas när den finns i lager.
Artikelnr: 390-01057
Tillverkarens artikelnummer: CONNECT-8X8 MP
EAN: 805676302447
24 840,00 SEK
decrease increase

INPUTS

  • Analog IN: 8 balanced inputs on 1 DSUB 25-pin connector
  • 8 microphone preamps with up to 72dB of gain
    • Featuring Advanced Stepped Gain Architecture™
  • *AES-EBU IN: 8 inputs on 1 DSUB 25-pin connector
    • (192k single wide compatible)
  • *Optical IN: Supports ADAT, SMUX & S/PDIF
    • ADAT: 8 channels 44.1-48 kHz
    • SMUX: 8 channels 88.2-96 kHz
    • S/PDIF: 2 channels, up to 96 kHz
  • Coax IN: 2 channels of S/PDIF, up to 192 kHz

OUTPUTS

  • Analog OUT: 8 balanced outputs on 1 DSUB 25-pin connector
  • *AES-EBU OUT: 8 outputs on 1 DSUB 25-pin connector
    • (192k single wide compatible)
  • *Optical OUT: Supports ADAT, SMUX & S/PDIF
    • ADAT: 8 channels 44.1-48 kHz
    • SMUX: 8 channels 88.2-96 kHz
    • S/PDIF: 2 channels, up to 96 kHz
  • Coax OUT: 2 channels of S/PDIF, up to 192 kHz

* Hardware switch selects AES or Optical digital input format
